Coulomb Blockade: A Quantum Charge Transport Phenomenon
“In the quantum hush of nanospace, a single charge can halt the race”
In the rapidly evolving landscape of electronics, smaller is not just better—it’s transformational. Over the decades, we’ve witnessed a dramatic reduction in transistor size, shrinking from 10 µm in the early days to just 10 nm by 2019, with leading companies like Intel and TSMC now targeting nodes as small as 2 nm by 2025–2026. Today’s silicon-based MOSFET technologies already operate within the nanoscale realm, with 22 nm CMOS nodes being commonplace. This aggressive miniaturization isn’t just a feat of engineering—it’s powered by cutting-edge material’s science. Nanostructured semiconductors such as CdSe, InAs, and CdS, often configured as quantum dots (QDs), have introduced entirely new quantum effects into device operation. One of the most notable is the Coulomb blockade, a phenomenon that enables precise control over individual electron flow. This effect lies at the core of single-electron transistors (SETs) and is opening doors to next-generation technologies like quantum computing and highly sensitive nanoscale sensors. Unlike traditional transistors that manipulate the movement of large numbers of electrons, SETs leverage the motion of a single electron, redefining the boundaries of what’s possible in nanoelectronics.
In this article, we explore the coulomb blockade in depth- its underlying physics, experimental observations, applications and its transformative potential in the next generation nanoelectronics system.
Historical Perspective: Where is coulomb blockade first observed?
The Coulomb blockade was first clearly observed in the late 1980s, with one of the earliest and most notable experimental demonstrations by T. A. Fulton and G. J. Dolan in 1987. They studied a small metallic island connected to leads via tunnel junctions, effectively creating one of the first single-electron transistors (SETs). Their work, published in Physical Review Letters, showed suppression of current at low bias voltages—a direct result of Coulomb charging effects—thereby confirming theoretical predictions of single-electron tunnelling behaviour. This pivotal experiment laid the foundation for the modern understanding and development of mesoscopic and nanoelectronics devices.
What is coulomb blockade?
In the realm of nanoelectronics, Coulomb blockade stands as a striking quantum phenomenon that dramatically alters how current flows at the nanoscale. While technical definitions—like the one from Wikipedia, which describes it as a “reduction in electrical conductance at small bias voltages in systems with low-capacitance tunnel junctions”—might sound daunting, the concept can be made intuitive with a simple analogy.
Imagine a tiny box, or “island,” capable of holding just one electron at a time. Since electrons repel each other due to their negative charge, adding a second one requires extra energy. If the applied voltage isn’t high enough to overcome this repulsion, the second electron simply can’t enter. This effect, where electrons are blocked from tunnelling unless certain energy conditions are met, is what we call Coulomb blockade—a sort of quantum traffic jam at the nanoscale.
Scientifically, Coulomb blockade is rooted in Coulomb’s law, which governs the electrostatic interaction between charged particles. This effect becomes particularly important at the mesoscopic scale—a middle ground between bulk materials and atomic structures. In bulk semiconductors (larger than 1 mm), electrons move in a random, diffusive fashion, bouncing off impurities and phonons. But as we shrink devices to the nanoscale, traditional laws of classical physics begin to give way to quantum behaviours.
At this scale, the limited space intensifies electron–electron repulsion, especially in nanostructures like quantum dots and single-electron transistors (SETs). The result? A blockade of current unless a specific threshold voltage is reached—highlighting how quantum mechanics can reshape our understanding of conductivity, resistance, and control at the smallest scales.
How It Works
Coulomb blockade, a quantum effect in mesoscopic physics, can be best understood through the role of tunnel junctions—ultra-thin insulating layers (a small island) placed between two conductive electrodes. While classical physics prohibits current flow through an insulator, quantum mechanics allows electrons to tunnel through this barrier when a bias voltage is applied. In a simple language this means that when a bias voltage is applied, there will be a current, and, neglecting additional effects, the tunnelling current will be proportional to the bias voltage. Essentially, a tunnel junction acts as a barrier to electron tunnelling, and when an electron tunnels across this barrier and into a small island, the resulting charge on the island can create a “Coulomb blockade”. Not only the tunnel has resistance but due to the presence of insulating layer, it also has a finite capacitance.
Due to the discreteness of electrical charge, current through a tunnel junction is a series of events in which exactly one electron passes (tunnels) through the tunnel barrier. The tunnel junction capacitor is charged with one elementary charge by the tunnelling electron, causing a voltage V is build up V=e/C , where C is the capacitance of the junction and e is the one electron charge.
If the device is very small (~ nano regimes), the capacitance is also small. If the capacitance C is very small, the voltage build up can be large enough to prevent another electron from tunnelling. This means that adding a single electron to the device significantly increase its energy, due to the charging energy. This energy barriers are what blocks further electron transport and the electric current is then suppressed at the low bias voltages. The resistance of the device starts varying and is no longer constant. The increase of the dynamic resistance around zero bias is called the Coulomb blockade.
.
Why Does Coulomb Blockade Occur in Quantum Dots—and Not Always in Other Nanostructures?
Quantum dots confine electrons in an extremely small, well-isolated region with very low capacitance. When an electron enters the dot, it creates a significant change in electrostatic potential—enough to prevent another electron from entering until sufficient energy (bias voltage) is supplied. While other nanostructures like nanowires and nanotubes can also exhibit some degree of Coulomb blockade, the effect is generally less pronounced. This is because their larger size leads to less pronounced energy level quantization and weaker electron-electron interactions compared to quantum dots.
What Makes Coulomb Blockade Possible?
A Key Conditions That Must Be Met
Coulomb blockade is not just any quantum quirk—it only emerges under specific physical conditions. To truly grasp when and why this phenomenon occurs, it’s important to understand the three essential requirements that must be in place:
- Coulomb blockade happens when a tiny space—like a quantum dot or nanoparticle—is so small that it can only hold one electron at a time.
- The space must have very low capacitance (so adding an electron needs extra energy).
- The temperature must be extremely low (to stop electrons from jumping in due to heat). That’s why cryogenic temperatures—often just a few degrees above absolute zero—are required.
- The island must be connected by special barriers called tunnel junctions. These barriers let electrons tunnel through one at a time instead of flowing freely.
When all these conditions are just right, current stops flowing unless enough energy is given—this is the Coulomb blockade.
Is coulomb blockade useful in practical device? What limits their real-world electronics implementation?
While Coulomb blockade-based devices are still largely in the research and experimental stages, real-world applications are starting to take shape—most notably through the development of single-electron transistors (SETs). These ultra-sensitive devices harness the Coulomb blockade effect to control the flow of individual electrons and are being explored for use in precision tools such as electrometers, ultra-accurate current standards, and even temperature reference systems. Researchers are also investigating SETs for cutting-edge fields like quantum computing and nanoscale charge detection. However, practical challenges—like the need for extreme miniaturization, cryogenic operating temperatures, and complex fabrication processes—still stand in the way of widespread, real-world deployment.
In Summary
At its core, Coulomb blockade is a remarkable quantum effect where the behaviour of just one electron can change everything. It occurs in ultra-small structures where space is so limited and temperatures so low that electrons must follow strict quantum rules. With precise control over electrical charge, this phenomenon showcases how the tiniest particles can influence the entire flow of current—turning the simple act of adding one electron into a powerful switch for next-generation electronics. As researchers and innovators continue to push boundaries, understanding effects like Coulomb blockade isn’t just academic—it’s the first step toward building the future, one electron at a time.
Sources
Fulton, T. A., & Dolan, G. J. (1987). Observation of single-electron charging effects in small tunnel junctions. Physical Review Letters, 59(1), 109–112. DOI:10.1103/PhysRevLett.59.109
https://www.waferworld.com/post/how-small-can-transistors-get
Fulton, T. A., & Dolan, G. J. (1987). Observation of single-electron charging effects in small tunnel junctions. Physical Review Letters, 59(1), 109–112. https://doi.org/10.1103/PhysRevLett.59.109
Grabert, H., & Devoret, M. H. (Eds.). (1992). Single Charge Tunneling: Coulomb Blockade Phenomena in Nanostructures. NATO ASI Series B: Physics, Vol. 294. Springer US.
Datta, S. (1995). Electronic Transport in Mesoscopic Systems. Cambridge University Press.
Kouwenhoven, L. P., et al. (1997). Electron transport in quantum dots. In Mesoscopic Electron Transport (Vol. 345, pp. 105–214). Springer. https://doi.org/10.1007/978-94-015-8839-3_4
Beenakker, C. W. J. (1991). Theory of Coulomb-blockade oscillations in the conductance of a quantum dot. Physical Review B, 44(4), 1646–1656. https://doi.org/10.1103/PhysRevB.44.1646
Averin, D. V., & Likharev, K. K. (1986). Coulomb blockade of single-electron tunneling, and coherent oscillations in small tunnel junctions. Journal of Low Temperature Physics, 62(3–4), 345–373.
